Lens specification | XF-10MDT0.44X110D-1C |
|---|---|
Lens type: | Objektseitig Telezentrisch |
Magnification | 0.44 |
coaxial insertion | Ja |
Image circle | Ø 16.2 mm |
Object circle | Ø 36.8 mm |
Working distance | 110 mm±3% |
Max. Sensor size | 1″ |
Max. Telecentricity error | 0.1° |
Max. Distortion | 0.018% |
Standard distortion | 0.018% |
Variable aperture | Nein |
Aperture | F8 |
Depth of field | 4.6 mm |
Resolution | 12 μm |
MTF | >125 lp/ mm |
Lens diameter | Ø 60 mm |
Lens length | 162.7 mm |
Weight | nicht eingegeben |
Standard Mount | C-Mount |
