XF-MT1.5X65
Object-Telezentrisches Objektiv für 2/3″ Sensor
Vergrößerung 1.5
Arbeitsabstand 65mm
Lens specification | XF-MT1.5X65 |
|---|---|
Lens type: | Objektseitig Telezentrisch |
Magnification | 1.5 |
coaxial insertion | nein |
Image circle | Ø 11 mm |
Object circle | Ø 7.3 mm |
Working distance | 65 mm±3% |
Max. Sensor size | 2/3″ |
Max. Telecentricity error | 0.15° |
Max. Distortion | 0.105% |
Standard distortion | 0.105% |
Variable aperture | Nein |
Aperture | F11.9 |
Depth of field | 0.55 mm |
Resolution | 5.2 μm |
MTF | >85 lp/ mm |
Lens diameter | Ø 25 mm |
Lens length | 86.1 mm |
Weight | nicht eingegeben |
Standard Mount | nach Anfrage |
