Lens specification | XF-MT1X110 |
---|---|
Lens type: | Objektseitig Telezentrisch |
Magnification | 1 |
coaxial insertion | nein |
Image circle | Ø 11 mm |
Object circle | Ø 11 mm |
Working distance | 110 mm±3% |
Max. Sensor size | 2/3″ |
Max. Telecentricity error | 0.07° |
Max. Distortion | 0.03% |
Standard distortion | 0.03% |
Variable aperture | Nein |
Aperture | F11.1 |
Depth of field | 1.2 mm |
Resolution | 7.3 μm |
MTF | >90 lp/ mm |
Lens diameter | Ø 34 mm |
Lens length | 126.7 mm |
Weight | nicht eingegeben |
Standard Mount | nach Anfrage |
