Lens specification | XF-PTL05511 |
---|---|
Lens type: | Bi-telezentrisch |
Magnification | 0.2 |
coaxial insertion | nein |
Image circle | Ø 11 mm |
Object circle | Ø 55 mm |
Working distance | 138 mm±3% |
Max. Sensor size | 2/3″ |
Max. Telecentricity error | 0.1° |
Max. Distortion | 0.1% |
Standard distortion | 0.1% |
Variable aperture | Nein |
Aperture | F8 |
Depth of field | 22 mm |
Resolution | 26.4 μm |
MTF | >130 lp/ mm |
Lens diameter | Ø 79 mm |
Lens length | 196.8 mm |
Weight | 1.33 Kg |
Standard Mount | C-Mount |
