Lens specification | XF-PTL05562 |
|---|---|
Lens type: | Bi-telezentrisch |
Magnification | 1.17 |
coaxial insertion | nein |
Image circle | Ø 62 mm |
Object circle | Ø 52.99145299 mm |
Working distance | 138 mm±3% |
Max. Sensor size | 62mm |
Max. Telecentricity error | 0.08° |
Max. Distortion | 0.1% |
Standard distortion | 0.1% |
Variable aperture | Ja |
Aperture | F6-F83 |
Depth of field | 1.2@F15 mm |
Resolution | 8.5@F15 μm |
MTF | >68@F15 lp/ mm |
Lens diameter | Ø 79 mm |
Lens length | 424.8 mm |
Weight | 2.73 Kg |
Standard Mount | M72 |
