Lens specification | XF-PTL39008 |
|---|---|
Lens type: | Bi-telezentrisch |
Magnification | 0.0205 |
coaxial insertion | Nein |
Image circle | Ø 8 mm |
Object circle | Ø 390.2 mm |
Working distance | 700 mm±3% |
Max. Sensor size | 1/2″ |
Max. Telecentricity error | 0.06° |
Max. Distortion | 0.128% |
Standard distortion | 0.128% |
Variable aperture | Nein |
Aperture | F5.5 |
Depth of field | 1348.7 mm |
Resolution | 177.4 μm |
MTF | >185 lp/ mm |
Lens diameter | Ø 430 mm |
Lens length | 1032.7 mm |
Weight | 58.98 Kg |
Standard Mount | C-Mount |
