Lens specification | XF-T0.5X65 |
|---|---|
Lens type: | Objektseitig Telezentrisch |
Magnification | 0.5 |
coaxial insertion | nein |
Image circle | Ø 11 mm |
Object circle | Ø 22 mm |
Working distance | 65 mm±3% |
Max. Sensor size | 2/3″ |
Max. Telecentricity error | 0.26° |
Max. Distortion | 0.001% |
Standard distortion | 0.001% |
Variable aperture | Nein |
Aperture | F16.7 |
Depth of field | 7.2 mm |
Resolution | 22 μm |
MTF | >60 lp/ mm |
Lens diameter | Ø 36 mm |
Lens length | 102.1 mm |
Weight | nicht eingegeben |
Standard Mount | C-Mount |
