XF-5MDT0.18X110
Bi-Telezentrisches Objektiv für 2/3″ Sensor
Vergrößerung 0.3
Arbeitsabstand 65mm
Lens specification | XF-5MDT0.18X110 |
|---|---|
Lens type: | Bi telezentrisch |
Magnification | 0.18 |
coaxial insertion | nein |
Image circle | Ø 11.2 mm |
Object circle | Ø 62.2 mm |
Working distance | 110 mm±3% |
Max. Sensor size | 2/3″ |
Max. Telecentricity error | 0.64° |
Max. Distortion | 0.007% |
Standard distortion | 0.007% |
Variable aperture | Nein |
Aperture | F6 |
Depth of field | 18.4 mm |
Resolution | 22 μm |
MTF | >175 lp/ mm |
Lens diameter | Ø 78 mm |
Lens length | 173 mm |
Weight | nicht eingegeben |
Standard Mount | nach Anfrage |
