XF-PTL08011

Bi-Telezentrisches Objektiv für 2/3″ Sensor

Vergrößerung 0.138

Arbeitsabstand 180mm

In die Anfrageliste legen
Lens specification
XF-PTL08011
Lens type:
Bi-telezentrisch
Magnification
0.138
coaxial insertion
nein
Image circle
Ø 11 mm
Object circle
Ø 79.7 mm
Working distance
180 mm±3%
Max. Sensor size
2/3″
Max. Telecentricity error
0.06°
Max. Distortion
0.1%
Standard distortion
0.1%
Variable aperture
Nein
Aperture
F8
Depth of field
46.5 mm
Resolution
38.39 μm
MTF
>130 lp/ mm
Lens diameter
Ø 104 mm
Lens length
247.1 mm
Weight
1.96 Kg
Standard Mount
C-Mount
